SLM SELF LOADING MIXE
I.S.ENGINEERING WORKS is the leading Self Loading Concrete Mixer Machine Manufacturer in Delhi and the Self Loading Concrete Mixer Machine Manufacturers in Faridabad.
OUR BROCHURES
CALL NOW +91-9873403301, +91-9718990613
| SLM SELF LOADING MIXER | |||||
| 1 | PARAMETER | SLM 2200 | SLM2200(T2.3) | SLM 2800 | SLM 4300 |
| 2 | ENGINE | 49.5 hp @ 2200rpm | 49.5 hp @ 2200rpm | 74.5 hp @ 2200rpm | 110 hp @ 2200rpm |
| 3 | DRUM OUTPUT | 2.2 M³ | 2.3 M³ | 2.8 M³ | 4.3 M³ |
| 4 | DRUM ROTATION | 0 to 22 Rpm | 0 to 22 Rpm | 0 to 21 Rpm | 0 to 21 Rpm |
| 5 | WATER TANK | 580 Lit | 580 Lit | 600 Lit | 800 Lit |
| 6 | FUEL TANK | 80 Lit | 80 Lit | 100 Lit | 110 Lit |
| 7 | BUCKET CAPACITY | 500 Lit | 500 Lit | 550 Lit | 650 Lit |
| 8 | WATER PUMP CAPACITY | 275 Lpm | 275 Lpm | 275 Lpm | 275 Lpm |
| 9 | VEHICLE SPEED | 0-23 Kmph | 0-23 Kmph | 0-25 Kmph | 0-29 Kmph |
| 10 | GRADEABILITY | 23o | 23o | 25o | 22o |
| 11 | UNLADEN WEIGHT | 6300 Kg | 6560 Kg | 7450 | 8450 Kg |
| 12 | TYRE | 12.5-18MT63 16PR HD | 12.5-18MT63 16PR HD | 12.5-18MT63 16PR HD | 405-70-20 MT54 14PR HD |
| 13 | DRIVE | 4 Wheel Drive | 4 Wheel Drive | 4 Wheel Drive | 4 Wheel Drive |
| 14 | VARIANT | Swivel | Non-Swivel | Swivel / Non-Swivel | Swivel / Non-Swivel |
